RELICTUM Current Cras Unit Courit Partger Current

XKinkong est professional evident partibus RELICTUM current Cras Unit Manufacturer et elit cum multis annis experientia. Vunts Current Cras Unit Multi Parts RELICTUM Cras Unit non occurrit multis applications, si vos es interested in qualis est in nostra qualis servicia, vos can consulere nos nunc, et nos mos adepto ad vos promptu, ut nos et nos mos adepto ad vos monola.an momenti in tuto et in omni virtute modules in terra. A defectivum ratio potest fieri periculo pro populo vel causa ignes. Antequam fit, potestas modules esse disconnect de malesuada. Et Leakage Current habet DC et AC components. Igitur per AC / DC-sensitive Cras Unit est.

Model:XKCA-01-MD

Mitte Inquisitionem

depictio producti

XKinkong est A EV DISCIPULUS partes RELICTUM Current Cras Unit Manufacturer et elit, bene notum qualis servitium. Wenzhou XKinkong Import & Export Co., Ltd. est innovative Enterprise integrationem scientificam investigationis, productio et venditionesque. In comitatu scriptor Sales network operit multis terris et regiones ut Europam et meridiem Asia, et ejus uber qualis et servitium sunt bene accepit a customers. Vos can requiem certo ad buy EV charger partes RELICTUM current Cras unitas ex nobis.

Et XKCA series RELICTU current Deprehensio module sit late applicabiles, praesertim in publico prćcipiens statio ad electrica vehicles, electrica motorcycles, electrica bicycles, præcipiens feodis, et potentia salus administratione. Hoc offert simplex usus et securus installation.

Features

■ Single Supple V V
■ Dual digital aperta-exhaurire output, 20Maac / 6Madc iter indication
■ III-phase Primam Condors in module (Typ. 32a, max. 40a)
■ PWM output ad DC RELICTUM current valorem indication (0 ~ 30ma)
■ Error output ad ratio culpa indication
■ mounted in PCB Board
■ auto-test munus

Applications

■ terra culpa deprehendatur

■ electrica vehiculum crimen station

■ Converter Leakage Current Deprehensio

Vexillum

■ Lorem ad IEC (LXII) DCCLII RELICTUM current requisitis

'■ Lorem IEC (LXII) CMLV RELICTUM current requisita ad RDC-PD

■ applicentur ad Ul2231 RELICTUM current RELICTUM

■ components disposito plena-satiata Radhs / pervenire

Product Partium

Typical application schematic:

Definitio ACUS:

PIN	Pin nomen	Munus
1	Error	■ aperto-collector output pin pro significatione ratio culpa conditione ■ Cum nulla ratio culpa, hoc pin et conducted ad gnd ■ Cum ratio culpa occurrit, quod pin erit summus impedimentis
2	Test-in	■ cum hoc pin conducted ad 0VDC, moduli mos calculate in nulla-punctum-PERFLUO et copia ad valorem ad subcriptio in DCU ad consummare calibration operationem. ■ Post calibration complevit, ratio interius generate simulata RELICTUM current, ut reprehendo utrum module potest facere rectam responsum. Per hoc procedure, x20-out & x6-sicco et conversus ad altus impeditance si moduli operationem rectam. Operam: ■ Cum usura in test-in function, pelagus circuitus sit Conscidisti-off ut non RELICTUM current fluxus ■ cum usura is pin munus, quaeso sequi tempus diagram figure
3	X6-sicco	■ Si RELICTUM current excedit pre-set DC tripling valorem (nam moduli typically 4.5 Madc), hoc output est in summus impedimento statu ■ cum totalis RELICTUM current R.M.S excedit pre-set omnes-current tripling valorem, hoc output est in summus impedimento statu ■ Cum ratio-culpa fit, hoc output est in summus impedimento statu ■ pro aliis normalis condiciones, hoc output est in humili gradu (GND)
4	X20, sicco	■ Si RELICTUM current excedit pre-set omnes, censuram, 17.8 MAAC enim pura-ac typically), hoc output est in summus impedimento civitate ■ Cum ratio-culpa fit, hoc output est in summus impedimento statu ■ pro aliis normalis condiciones, hoc output est in humili gradu (GND)
5	Gnd	■ terra
6	VDDD	■ OMNIBUS potentia copia, Latin voltage 5vdc ■ Voltage input requiritur ad esse intra 4.85 ~ 5.15VDC, Power output capability> 100ma ■ potentia copia lacum ≤ 150mv (Est suggesserant ad usum LDO Circuit, quia Reference IC LP2985A-50DB)
7	Pwm	■ demonstrando DC RESIDUUS Current component cum officium-cycle cum 8khz Pwm ■ output resolution = 3.33% / Madc from 0 ~ 30Madc ■ accurate circa ± 0.5ma
8	N.c.	■ non solebat

Electrical / Reliability characteres:

	Iacto	Min	Type	Max	Unitas
1	Primary Nominal RMS Current (1Phase / 3Phase)		32	40	A
2	Copia voltage	4.85	5	5.15	V
3	Ambientium operatio temperatus	-40		CV	℃
4	Ambientium repono temperatus	-20		LXV	℃
5	Vestibulum Power consummatio			110	MW
6	Electrical alvi: primaria primaria	6.5			mm
7	Electrical alvi, primaria secundarium	10			mm
8	Creepage distantiam primaria primaria	8			mm
9	Creepage distantiam primaria secundarium	10			mm
10	Voltage input, humilis campester	0		0.6	V
11	Voltage input, princeps gradu	4.2		5	V
12	Theoretical Design vitae	20			C.
13	Operating altitudinis			4000	m

TRIP, Current (RELICTUM Current Related Charles):

	WAV	Freq	Min	Type	Max	Unitas
1	Ac	50Hz	15	17.8	20	MA
2	A0	50Hz	11	17	26	MA
3	A90	50Hz	10	18.5	27	MA
4	A135	50Hz	10	22.9	28	MA
5	2pdc	-	3.5	5.0	7	MA
6	3pdc	-	3.1	4.5	6.2	MA
7	S-DC	-	3.0	4.5	6.0	MA

Time Time (RELICTUM Current Relatistics):

	WAV	Freq	Current	Type	Max	Unitas
1	Ac	50Hz	30ma	50	1000	MS
2	Ac	50Hz	60ma	16	100	MS
3	Ac	50Hz	150A	15	60	MS
4	Ac	50Hz	5A ~ 100a	8.5	60	MS
5	A0	-	42ma	25	100	MS
6	A0	-	84MA	18	60	MS
7	A0	-	210MA	10	60	MS
8	A0 + DC	-	42ma + 6madc	18	60	MS
9	A0 + DC	-	84ma + 6Madc	15	60	MS
10	A0 + DC	-	210MA + 6madc	15	60	MS
11	S-DC	-	6ma	48	1000	MS
12	S-DC	-	60ma	16	100	MS
13	S-DC	-	300MA	8.5	60	MS
14	2pdc / 3pdc	-	60ma	20	100	MS
15	2pdc / 3pdc	-	120ma	15	60	MS
16	2pdc / 3pdc	-	300MA	12	60	MS
17	2pdc / 3pdc	-	5A ~ 100a	12	60	MS

Product dimensionem (mm):

Sincere Diagram:

■ T0 sicut expectans tempus systematis stablization, T0≈ 270ms

■ T1 quod expectans tempus, quod est suggesserant T1 ≥ 100ms

■ T2 sicut calibration et auto-test ordine tempus, id est suggesserant 50ms ≤ T2 ≤ 100ms

■ T3 sicut expectans tempus pro ipso test DC, T3≈ 200ms, id est suggesserant legere x6-sicco post 300ms

■ T4 sicut expectans tempus pro ipso test AC, T4≈ 690ms, id est suggesserant ad legere x30, de post 300ms

■ T5 ut AC auto-test indication Duratio est tempus, T5 ≈ 1580ms

■ T6 sicut DC sui test indication Duratio tempus, T6 ≈ 1090Ms

Sui test Circuit:

■ II widing in zct ad generare simpliciter DC RELICTUM current

■ per usura VDD ad generare typicam valorem = 6.53 Madc simulavit RELICTUM current

■ Hic current est maxime restricted tripping conditio ad test si systematis est opus recta

Digital Signum Flip limina:

■ ad vitandum signum oscillationis, spatio signo output flipping est paro cum tripping limine et recuperatio limen

■ cum tria limina pervenit et related X de flip et cum current decrementum ad recuperare limina Related X de Flip iterum, ad humilis campester civitatis
